MCP ECharts

Generate Apache ECharts diagram and chart with AI MCP dynamically. Using for chart generation and data analysis.

✨ Features

• Fully support all features and syntax of ECharts, include data, style, theme and so on.
• Support exporting to png, svg, and option formats, with validation for ECharts to facilitate the model's multi-round output of correct syntax and graphics.
• MinIO Integration, store charts in MinIO object storage and return URLs instead of Base64 data for better performance and sharing capabilities.
• Lightweight, we can install it easily with zero dependence.
• Extremely secure, fully generated locally, without relying on any remote services.

🤖 Usage

Desktop Applications (stdio transport)

To use with Desktop APP, such as Claude, VSCode, Cline, Cherry Studio, and so on, add the MCP server config below. On Mac system:

{
  "mcpServers": {
    "mcp-echarts": {
      "command": "npx",
      "args": [
        "-y",
        "mcp-echarts"
      ]
    }
  }
}

On Window system:

{
  "mcpServers": {
    "mcp-echarts": {
      "command": "cmd",
      "args": [
        "/c",
        "npx",
        "-y",
        "mcp-echarts"
      ]
    }
  }
}

Also, you can use it on modelscope, glama.ai, smithery.ai or others with HTTP, SSE Protocol.

🚰 Run with SSE or Streamable transport

Install the package globally.

npm install -g mcp-echarts

Run the server with your preferred transport option:

# For SSE transport (default endpoint: /sse)
mcp-echarts -t sse

# For Streamable transport with custom endpoint
mcp-echarts -t streamable

Then you can access the server at:

• SSE transport: http://localhost:3033/sse
• Streamable transport: http://localhost:3033/mcp

🎮 CLI Options

You can also use the following CLI options when running the MCP server. Command options by run cli with -h.

MCP ECharts CLI

Options:
  --transport, -t  Specify the transport protocol: "stdio", "sse", or "streamable" (default: "stdio")
  --port, -p       Specify the port for SSE or streamable transport (default: 3033)
  --endpoint, -e   Specify the endpoint for the transport:
                    - For SSE: default is "/sse"
                    - For streamable: default is "/mcp"
  --help, -h       Show this help message

🗂️ MinIO Configuration (Optional)

For better performance and sharing capabilities, you can configure MinIO object storage to store chart images as URLs instead of Base64 data.

[!NOTE]
If MinIO is not configured or unavailable, the system automatically falls back to Base64 data output, ensuring compatibility.

We can Integrate with MinIO object storage providers below.

• MinIO: High-performance, S3-compatible object storage. Use MinIO JavaScript Client for direct integration.
• Amazon S3: Use AWS SDK with compatible API endpoint.
• Alibaba Cloud OSS: Use the Alibaba Cloud SDK for OSS services.
• Google Cloud Storage: Integrate using Google Cloud SDK or compatible API.
• Microsoft Azure Blob Storage: Use Azure SDK for Blob storage access.
• Tencent Cloud COS: Use the Tencent Cloud SDK for COS integration.

Also, we can setup MinIO locally for free.

1. Install and start MinIO locally:

   # Download MinIO (macOS example)
   brew install minio/stable/minio

   # Start MinIO server
   minio server ~/minio-data --console-address :9001


2. Configure environment variables:

   # Copy the example environment file
   cp .env.example .env

   # Edit .env with your MinIO settings
   MINIO_ENDPOINT=localhost
   MINIO_PORT=9000
   MINIO_USE_SSL=false
   MINIO_ACCESS_KEY=minioadmin
   MINIO_SECRET_KEY=minioadmin
   MINIO_BUCKET_NAME=mcp-echarts


🔨 Development

Install dependencies:

npm install

Build the server:

npm run build

Start the MCP server:

npm run start

🧑🏻‍💻 Contributors

• lyw405: Supports 15+ charting MCP tool. #2
• 2niuhe: Support MCP with SSE and Streaming HTTP. #17
• susuperli: Use MinIO to save the chart image base64 and return the url. #10
• BQXBQX: Use @napi-rs/canvas instead node-canvas. #3
• hustcc: Initial the repo.

📄 License

MIT@hustcc.
