ros-mcp

ROS MCP

ROS MCP is a MCP server designed for controlling robots in ROS environments using natural language.
It supports communication via ROS topics, services, and actions, and works with any ROS message type.

Demo

Test to see if ros topics, services, and actions can be used.

https://github.com/user-attachments/assets/61143c37-fb73-4998-9cbc-844d92ae61d9

Components

• Socket Server (socket_server.py): A lightweight server that runs on localhost:8765 to handle GUI-related operations.
  It receives instructions from the MCP server to launch tools such as Gazebo or rqt_graph on the local display.

• MCP Server (ros-general.py): A Python-based server that implements the MCP.
  It processes natural language input, maps it to ROS commands, and communicates with the socket server.
  To enable node communication between the MCP server and the local machine, both must be configured with the same ROS_DOMAIN_ID on the same local network.

Overview of MCP Tools

• Topic Management: List, monitor, and publish to ROS2 topics
• Node Control: List and inspect running ROS2 nodes
• Service Interaction: Call ROS2 services with custom
• Action Support: Send goals to ROS2 actions
• GUI Integration: Launch ROS2 GUI tools via WebSocket server
• Environment Debugging: Check ROS2 setup and configuration
• Process Management: Clean up running ROS2 processes

Please refer here for more details.

Getting Started

Requirements

• ROS2 Humble Hawksbill (This project has only been tested with ROS2 Humble. Compatibility with other ROS2 distributions is not guaranteed.)
• claude desktop (Linux, macOS and Windows)
• Python 3.10+
• websockets >= 15.0.1
• uv package manager (Installing uv)
• Other dependencies as listed in pyproject.toml

Installation

Git clone and install websockets package

git clone git@github.com:Yutarop/ros-mcp.git
cd ros-mcp
pip install "websockets>=15.0.1"

Activate .venv and install dependencies

uv venv
source .venv/bin/activate
uv pip install -e .

Claude Settings (claude_desktop_config.json)

To use the MCP server correctly with Claude Desktop, you need to modify the claude_desktop_config.json file with appropriate values.

{
  "mcpServers": {
    "ros-general": {
      "command": "uv",
      "args": [
        "--directory",
        "/ABSOLUTE/PATH/TO/PARENT/FOLDER/ros-mcp",
        "run",
        "bash",
        "-c",
        "export ROS_LOG_DIR=/tmp && export ROS_DOMAIN_ID=${ROS_DOMAIN_ID:-YOUR_ROS_DOMAIN_ID} && source /opt/ros/humble/setup.bash && python3 /ABSOLUTE/PATH/TO/PARENT/FOLDER/ros-general.py"
      ]
    }
  }
}

💡 Replace the following placeholders:

• /ABSOLUTE/PATH/TO/PARENT/FOLDER/ros-mcp
  Replace with the absolute path the ros-mcp directory.
  For example: /home/ubuntu/ros-mcp

• YOUR_ROS_DOMAIN_ID
  Replace with the ROS domain ID used in your environment to enable ROS communication between the MCP server and your local machine. If you're not sure what your current domain ID is, you can check it by running the following command in your terminal:

  echo $ROS_DOMAIN_ID


  If nothing is printed, the domain ID is not set, and the default value 0 will be used.
  Alternatively, you can set it manually using the following command:

  export ROS_DOMAIN_ID=10  # Replace 10 with your desired domain ID


• /ABSOLUTE/PATH/TO/PARENT/FOLDER/ros-general.py
  Replace with the absolute path to your ros-general.py script.
  For example: /home/ubuntu/ros-mcp/ros-general.py

Running the Servers

Start MCP server

Make sure your virtual environment is activated before running the MCP server:

(ros-mcp) $ uv run ros-general.py

Start socket server

python3 socket_server.py

💡not in the virtual environment!
